Product information "Platinum Bath JE18 - 2 g/L Pt"
The acid platinum electrolyte JE18 deposits shiny, bright and hard platinum layers. It is used for decorative as well as technical applications. The layers are highly resistant to corrosion and abrasion.
Operating data:
Platinum content: 2,0 g/L
pH-value: <1
Density: 1,08 g/ml, increasing
Operating conditions:
Voltage: 2 Volt
Bath temperature: 30 - 40 °C
Exposition time: 2 - 4 min.
Anodes: Platinized titanium, Mixed oxide
Anode/Cathode surface: 1 : 1
Goods movement: required
Recommended velocity: 2 - 8 cm/sec.
Deposition rate: ca. 11 mg/Amin; ca. 0,5-1,5 A/dm2
Bath movement: recommended
Bath filtration: from 10 litres
Deposition data:
Hardness: 500 HV
Layer thickness: max. 1,0 µm
Pt content: 99,9%
Form of delivery:
Ready for use 2 g/L Pt
Operating data:
Platinum content: 2,0 g/L
pH-value: <1
Density: 1,08 g/ml, increasing
Operating conditions:
Voltage: 2 Volt
Bath temperature: 30 - 40 °C
Exposition time: 2 - 4 min.
Anodes: Platinized titanium, Mixed oxide
Anode/Cathode surface: 1 : 1
Goods movement: required
Recommended velocity: 2 - 8 cm/sec.
Deposition rate: ca. 11 mg/Amin; ca. 0,5-1,5 A/dm2
Bath movement: recommended
Bath filtration: from 10 litres
Deposition data:
Hardness: 500 HV
Layer thickness: max. 1,0 µm
Pt content: 99,9%
Form of delivery:
Ready for use 2 g/L Pt
