White gold in particular is often plated with platinum

Platinum Bath JE18 -2g/L
Platinum Bath JE18 for high-gloss and hard platinum layers The acid platinum electrolyte JE18 deposits shiny, bright and hard platinum layers. It is used for decorative as well as technical applications. The layers are highly resistant to corrosion and abrasion. Operating data: Platinum content: 2,0 g/l pH-value: <1 Density: 1,08 – 1,09 g/cm3 Operating conditions: Voltage: 1,7-2,4 Volt Bath temperature: 25-45°C Exposition time: 5-15 min. Anodes: Platinized titanium, mixed-metal-oxide Anode/Cathode surface: 1 : 1 Current density: 1,0 – 1,5 A/dm2 Bath filtration: from 10 litres Deposition rate: 8 - 11 mg/Amin approx. 0,08 µm/min Deposition data Hardness: approx. 500 HV Layer thickness: max. 1,0 µm Layer density: approx. 21 g/cm3 Pt content: 99,9% Danger! H314 - H290 Available Downloads • Safety Data Sheet • Product information
